Mounting your TV on the wall is one of the best upgrades you can make to a living room or bedroom. It frees up floor space, improves viewing angles, and gives your setup a clean, modern look. But with dozens of bracket types and specifications to consider, it's easy to feel overwhelmed. This guide breaks it all down so you can choose the right TV wall bracket with confidence.
Step 1: Know Your TV's VESA Pattern
VESA (Video Electronics Standards Association) is the universal standard for the bolt-hole pattern on the back of your TV. It's measured in millimetres — for example, 200×200 or 400×400 — and your bracket must match your TV's VESA pattern exactly.
You'll find your TV's VESA pattern in its manual or on the manufacturer's website. Common patterns include:
- 100×100 — small TVs up to 32"
- 200×200 — mid-size TVs 32"–43"
- 400×400 — large TVs 50"–65"
- 600×400 or 800×400 — very large TVs 65"+
Most brackets support a range of VESA patterns, so always check the bracket's compatibility list before buying.
Step 2: Choose the Right Bracket Type
There are four main types of TV wall bracket, each suited to different rooms and viewing habits.
Fixed (Flat) Brackets
The simplest and most affordable option. Your TV sits flush against the wall with no movement. Ideal if your TV is directly opposite your seating and you never need to adjust the angle. These are also the most low-profile — great for a clean, minimal look.
Tilting Brackets
Allow you to angle the screen downward (typically 5°–15°), which is useful if your TV is mounted higher than eye level — above a fireplace, for example. Tilting brackets are a popular middle ground between fixed and full-motion.
Full-Motion (Articulating) Brackets
Offer the most flexibility — you can tilt, swivel, and extend the TV away from the wall. Perfect for open-plan rooms where you watch from multiple positions, or corner installations. The B-Tech BT8229 Ultra Slim Double Arm Wall Mount is a great example, combining a slim profile with full tilt and swivel movement.
Long-Reach / Extension Brackets
A specialist type of full-motion bracket with an extended arm — sometimes reaching 600mm–1000mm from the wall. Ideal for corner mounting, wrapping around pillars, or positioning a TV to be visible from two rooms. The Multibrackets M Universal Long Reach Arm (1010mm) is one of the longest-reach brackets available.
Motorised Brackets
The premium option — your TV moves at the touch of a button or via an app. The Vogels Signature TVM 7675 Black Motorised TV Wall Bracket for screens up to 77" lets you swivel and tilt your screen electrically, ideal for home cinema rooms or anyone who wants a truly effortless setup.
Step 3: Check the Weight Rating
Every bracket has a maximum weight rating. Weigh your TV (or check the spec sheet) and make sure the bracket you choose is rated above that figure — ideally with some headroom. A 65" OLED can weigh 25–35kg, so don't underestimate this.
Step 4: Consider Your Wall Type
This is where many people come unstuck. The wall type determines what fixings you need and whether a bracket is safe to install at all.
- Solid brick or concrete — the easiest wall to mount on. Use masonry bolts and a hammer drill.
- Stud partition walls (timber frame) — you must fix into the studs, not just the plasterboard. Use a stud finder and long wood screws.
- Plasterboard (dot-and-dab) — the trickiest. Standard plasterboard fixings won't hold a heavy TV safely. You'll need specialist cavity fixings or to locate the masonry behind. See our dedicated guide on how to mount a TV on plasterboard for full advice.
Step 5: Think About Cable Management
A wall-mounted TV looks best when cables are hidden. Consider whether you want to run cables inside the wall (requires an electrician for mains cables in the UK) or use surface-mounted cable trunking. Some brackets include integrated cable management clips — worth looking for if a tidy finish matters to you.
Step 6: Check Screen Size Compatibility
Brackets are rated for a range of screen sizes as well as VESA patterns. A bracket rated for 32"–65" screens won't necessarily suit a 75" TV — the mounting arms may not span wide enough. Always cross-reference the bracket's maximum screen size with your TV's diagonal measurement.
Our Recommended TV Wall Brackets
Browse our full range of TV wall brackets, including:
- Ultra-thin flat brackets for a flush, minimal look
- Motorised TV wall brackets for effortless adjustment
- The Multibrackets PUSH0513 Recessed Push-to-Release Bracket — a unique recessed design that hides completely flush with the wall when not in use
Still not sure which bracket is right for your setup? Browse our full TV brackets collection or get in touch — we're happy to help you find the perfect match.
